 PostPosted: Mon Sep 06, 2010 8:41 pm    Post subject: Polaris cooling system Reply with quote Back to top

Well the Polaris 500 Sportsman is having coolent issues.

Did you know..... the temperature sensor that turns the fan ON
is at the very top of the Rad... DUMB...

ours was low on antifreze, therefor the sensor wasnt in the coolent...
so fan wont come on.. only way we knew was the Idiot light on the pod

Micki and I stripped it down, filled the rad up and noticed some coolent
was leaking out of the bottom of the water pump..

It is kinda like the old chevy waterpumps.. there is a little blow off or vent
hole or something.. still have to research this but here is some pics..









_________________
Hondas Dont Impress Me!
YAMAHA IS KING !
OF4WD # 5277


View user's profile Send private message Feedback Rating
Sam



Age: 41
Joined: 26 Apr 2007
Posts: 2027
Location: Belleville

 PostPosted: Mon Sep 06, 2010 8:55 pm    Post subject: Reply with quote Back to top

Be interesting to see what the cause is.

Bushy should know.... He's replaced eveything except handle bars on his polaris. rockout

_________________
2008 Honda Rubicon (HULK)
27" OutLaws
Mudbuster Cam
Hmf exaust
2" Lift (Not installed yet)
K&N Air and Dynojet kit
Highlifter BigBore kit (550cc) (Not installed yet)

View user's profile Send private message Feedback Rating
BadThumper
Site Admin


Age: 49
Joined: 26 Apr 2007
Posts: 6869

 PostPosted: Mon Sep 06, 2010 9:54 pm    Post subject: Reply with quote Back to top

WEEP HOLE LEAKING...


The weep hole should be on the right side of motor near bottom. There have been many instances of this. I have been through a few. It is due to the mechanical seal leaking inside. Some have changed theirselves but if you bend the shaft then the motor has to come apart. Do a search for weep and should find lots of discussion on it.

http://forums.atvconnection.com/polaris/313188-01-polaris-sportsman-500-ho-weep-hole-leaking.html

_________________
Hondas Dont Impress Me!
YAMAHA IS KING !
OF4WD # 5277


View user's profile Send private message Feedback Rating
BadThumper
Site Admin


Age: 49
Joined: 26 Apr 2007
Posts: 6869

 PostPosted: Mon Sep 06, 2010 9:58 pm    Post subject: Reply with quote Back to top

http://forums.atvconnection.com/polaris/213306-2004-sportsman-400-leaking-coolant-wheap-hole-2.html

Looks like i will be taking it to DeerHaven... Sad

_________________
Hondas Dont Impress Me!
YAMAHA IS KING !
OF4WD # 5277


View user's profile Send private message Feedback Rating
thompy



Age: 33
Joined: 08 Nov 2008
Posts: 487

 PostPosted: Tue Sep 07, 2010 5:58 pm    Post subject: Reply with quote Back to top

yeah thats a common problem with the polaris's my 700 had the same thing. Another big thing, there is a tiny air vent on the coolant reservoir cap that vents the air out. It gets clogged and pressurizes the system. best fix is drill a little hole and screw a grease zerk in and attach a vent line up high.
_________________
2011 dodge larime leveled 33s
2013 Can Am outlander 1000 XT-P
29.5 Terms QsC, STM Tuned
2008 Can Am Renegade 800x some goodies

View user's profile Send private message Feedback Rating MSN Messenger
